Compact High Capacity Hammer Mill Machine Corn Grinder For Chicken Feed

Brand Name : FAR

Model Number : SFSP998

Certification : CE ISO9001:2000

Place of Origin : China

MOQ : 1 set

Price : Negotiable

Payment Terms : L/C, T/T

Supply Ability : 50 sets per year

Delivery Time : 30 days

Packaging Details : iron pallet

Design : Compact

Condition : New

Power : Call For Details

Voltage : 380V

Motor : Siemens

Bearing : SKF

Material : Steel

Warranty : 1 Year

Contact Now

Automatic Corn Mill Grinder Machine Producing Poultry Broiler Feed 1 Year Warranty

Our company is specialized in manufacturing grinding machinery, rice mill,flour mill, poultry feed crusher, livestock feed crusher ,feed making crusher, grain crusher so on.

Product Description

Features:

1. It is widely used in various feed mills, oil plants, alcohol plants, citric acid plants, etc;
2. The bottom of grinding chamber is fitted with U-shape double grinding structure, further improving the capacity with more consistent particle size;
3. All of our rotors pass an accurate dynamic balancing test, resulting in low noise and smooth running. The imported components are used for key parts, resulting in long service life and low maintenance cost;

4. Both coarse and fine grinding can be completed by adjusting the distance between the beater and the screen;
5. New type S-shape coupling directly connecting driving results in big offset travel and effectively avoid the heat from the bearing;
6. Beater blade edge is vacuum-welded by special alloy steel, resulting in long service life;
7. The moving full-wide operation door facilitates maintenance and replacing of beater;

Main Technical Parameters:

Model Parameters	SFSP998-1	SFSP998-2	SFSP998-3	SFSP998-4	SFSP998-5
Dia. Of Rotor(mm)	1120	1120	1120	1120	1120
Width Of Grinding Chamber (mm)	300	380	500	750	1000
Speed Of Rotor(rpm)	1480	1480	1480	1480	1480
Power(kw)	55/75	90/110	132/160	200/220	220/250/280
Output(t/h)	10-18	15-20	22-35	34-50	45-60

Re: The above indexes are those when meeting the following conditions: raw material: corn, moisture content not higher than 14%, density not lower than 0.72t/m³, screen: hole diameter 3mm, hole-opening rate not less than 33%.

Details

Compact High Capacity Hammer Mill Machine Corn Grinder For Chicken Feed
